In the pursuit of designing our own tooling and devices we have procured and upgraded our CNC Router now with abilities to machine Aluminuim,  non ferrious metals and high end plastics such as Acetyl. We use Fusion 360 for our CAM operations and Sharkcad PRO for our CAD drawings.

Contact us now to discuss your project. We are competitive and professional.

`We have upgraded. ATC Spindle: 6Kw ER32 3Phase Spindle Max Endmill Size: 46mm Facing Cutter Spindle Min Endmill Size: 1.0mm Table Dimensions: Cast T Slot Table - 1100mm x 900mm Main Router Table Dimensions (include rear table) : 2200 x 1100mm Software: Fusion 360 ; SharkCad Pro ; Mach 3 On-hand stock: 6061 Aluminium Various Sizes ; 5083 6mm Sheet ; 5083 10mm Sheet Outsourcing Services: Aluminium Polishing and Anodising available.

	In Jan 2022 we were tasked with the design and manufacture of a self centering vise to finish a component design prototype. Inside the scope of design was a requirement was to create flat surfaces on the clamping portion to accept rubber feet. We also created the mould for these feet. The centre pin is steel. Bushings on the slide rod we used Acetyl. The only part in this assembly we outsourced was the handle at $16. A RH and LH thread was required to make this work. In all a very successful project.
No job too small we were tasked with the design and manufacture of a series of 50mm bushes to secure 16mm rod. These we designed in SharkCad and machined out of 6061 Aluminuim
	We were approached by Opritech NZ Ltd with a request to remanufacture this theatre positioning paddle. Requirements were for for it to withstand the 138deg pulses inside a hospital stereliser. We chose Teflon for this purpose and pressed it onto a 316 SS rod to make it work. Client was so happy they asked for all of their stock to be remanufactrured this way.
In our own equipment upgrade for precision, accuracy and speed we decided to install 8.5A Nema 34 Motors and 25mm BallScrews. The X Axis on our machine was a very low profile design. To install the much larger Nema 34 we needed a low profile bracket to accept the motor and end bearing. This three piece assembly was designed and machined out of 6061 Alloy. The double angular bearings are a press fit for full rigidity. This was such a success we have kept this design and used it several times.

Rata CNC 6Kw Router

Our 4 way CNC Modular Vice allows us to machine four parts simutainously. This greatly speeds up process, giving you our client a very cost effective solution for multiple componenent manufacture.
